Model 1911 Pistols Disassembly and Reassembly Guide - Gun Guides
Manual includes information on all models (M1911, M1911A1, Series 70/80 and all variants). Easy to use -- Comb binding lies open and flat on your work surface. 16 pages & 20+ high-resolution grayscale images. Cardstock cover. Bright white paper.
Includes a brief history of the 1911 Series Pistols with exploded parts view with 54 part names.
Disassembly instructions cover Safety First, Different types of recoil spring assemblies, Barrel bushings, Slide stop, Slide, Guide rod and recoil spring(s), Remove barrel bushings, Barrel, Firing pin stop plate, Firing pin, Extractor, Grip panels, Safety, Safety lock plunger, Mainspring housing and pin, Slide release plunger and spring, Grip safety, Sear Spring, Hammer pin and hammer assembly, Sear Pin, Sear, Disconnector, Magazine catch and Trigger assembly. Also
Reassembly and tips.
