Ruger Single Action Revolver Disassembly and Reassembly Guide - Gun Guides
Manual includes information on all models (Blackhawk, Super Blackhawk, Vaquero and Bisley Models). Easy to use Comb binding lies open and flat on your work surface. 16 pages & 20+ high-resolution grayscale images. Cardstock cover. Bright white paper.
Includes an Introduction, Brief History, Safety First, Exploded Parts Diagram and Parts List.
Disassembly instructions cover, Clear Weapon, Grips, Mainspring, Grip Frame Screws, Grip / Cylinder Frames, Pawl Spring, Cylinder Latch, Old Three Screw Models, Trigger Spring, Trigger Pivot Pin, Gate Detent Spring Clamp, Hammer & Cross Pin, Transfer Bar, Trigger, Cylinder Stop, Gate Spring, Loading Gate, Hammer Plunger & Spring and Ejector & Housing.
Reassembly includes (21) Listed Steps and Tips. Also a list of accessories.
